FIRST USE
To help you get to grips with your new ride, here are some tips on using your EDR for the first time:
REF: 8775069
EDR CF RIM ULTEGRA DI2
2021
Welcome to the support sheet for your EDR CF RIM ULTEGRA DI2.
This page contains all our very best advice for using, maintaining and repairing your EDR: user guide, servicing, repairs and spare parts.
UNBOXING
VAN RYSEL EDR CF
TYRE PRESSURE
For your first outing, remember to choose your tyre pressure, depending on the weather conditions and your weight.
TORQUE SETTINGS
Please respect the torque settings, especially the settings for the stem/handlebars (please see the user guide), which can cause a fall if they are not tightened properly.
To set your position properly on the bike, carry a set of Allen keys with you on your rides.
ADJUSTING YOUR POSITION
Steering position
To adjust your position, you can remove the "spacers" located under the stem. Once you've set everything up as you want, don't be afraid to cut the part of the blade that comes above the stem. We recommend getting a professional to do this in one of our bike workshops.
USING YOUR ELECTRIC DRIVE TRAIN
Battery charger
To replace your gears, derailleurs and levers use a battery. Each derailleur has a battery that you can recharge using the charging station supplied with the bike.
MAINTENANCE
Maintaining your bike is essential if you want to expand its lifecycle. That starts with regularly cleaning your bike, the frame and drive train.
Step 1
Apply a degreaser to your drive train. Place a cloth on top of the brake discs to prevent them from being covered with degreaser.
Step 2
Clean your drive train with the aid of a brush. Apply a suitable cleaning product to your frame.
Step 3
Drying your bike and lubricating your drive train.
Find all the info you need to keep your bike in good shape
Essential tools for your workshop.
What checks do you need to make before going out on the bike?
What pressure should the tyres on your bike be?
When to change your tyres
What should you do if you hear creaking while riding?
Since both the frame and the seat post are made of carbon, you can sometimes hear a creaking sound while riding.
It is often due to a seat post that isn't greased sufficiently.
Disassemble the seat post, apply a bit of carbon grease on the seat post, and then reposition it to the correct adjustment.
When to change your chain
The chain is a key part of your bike's drive train.
It is an important part of the drive train, since it connects the bottom bracket and the cassette.
It transfers energy for efficient movement, so it is fundamental to keep your chain in good condition.
In this article, you'll find out how to recognise a worn-out chain:
When to change your brake pads
It is time to replace your brake pads when they aren't as reactive as they were at first; that is, they lack a little bite.
If you hear an abnormal sound when braking abruptly, that can be a sign of wear.
It's always worth checking how much brake pad lining is left.
You'll need to change the pads if the lining is less than 0.5 mm thick.
When should you replace your discs?
Although disc brakes are designed to wear out the brake pads and not the disc, the disc will end up wearing out through use over time.
It can be dangerous to ride with an overly worn disc; it can give out if you brake suddenly or intensely.
The maximum wear value for a disc corresponds to around 10% of its original value.
Repairs
Here are some tips for changing a part on your bike. Can't find an answer to your issue? Contact our technicians using the "Assistance" button below, or make an appointment at your Decathlon workshop.
CHANGING YOUR PEDALS
Are your pedals broken? Do you want to change your pedals for clipless ones? Here's our advice.
NB: please note that the screw thread on the left pedal is inverted and that the pedal thus screws on in an anti-clockwise direction. The right pedal has a standard screw thread.
Please use the correct tool to take your pedals off as force needs to be exerted to unscrew them.
CHANGING YOUR INNER TUBE
CHANGING YOUR HANDLEBAR TAPE
YOUR BIKE ISN'T BRAKING VERY WELL
There are several things you can do if your brakes aren't working as well as they used to:
- Use a bike cleaning product to clean the rims and pads.
- Check the brake pads for wear.
- Check the tension of the cable.
CHANGING YOUR BRAKE PADS
Your derailleur isn't able to shift gears any more
If your derailleur is no longer responding to your gear changes, you may have to replace the cables and housings on the derailleur.
Watch our video tutorial to find out how:
YOUR GEARS ARE SKIPPING
If the gears are skipping, you should check the following:
- The wear on your drive train.
- The tension of the cables.
If the problem lies elsewhere, then you should adjust your derailleur.
SPARE PARTS
VAN RYSEL EDR
Shimano ULTEGRA DI2
Assistance
Need a hand? Ask our expert technician!
User guides & certificates
Accreditation certificate
VAN RYSEL EDR CF RIM ULTEGRA DI2
Drive train
ULTEGRA DI2
workshop services
You can try to do all these jobs yourself or you can visit the workshop at your Decathlon store and ask us to do them for you. For more information on the services offered by the workshop, please click on the link below.
