ELECTRIC FOLDING BIKE B'TWIN E FOLD 100

2023

On this page you will find the assembly, maintenance and repair instructions for your bike.
If needed, you will find the link to all available spare parts for your product.

GETTING STARTED WITH YOUR BIKE

Take delivery, unpack it, and off you go!

Find the answers to all of the questions you might have the first time you use your bike.
Ready to head out on your bike for the very first time? Before you step outside, there are a few bits and pieces to check ;)

Unboxing:

Electric folding bike E FOLD 100: user guide, repairs

Folding and unfolding:

Electric folding bike E FOLD 100: folding and unfolding

What should you check before riding?

Before using your bike for the first time, check that:
- the hinges on the frame and stem are correctly locked in place
- the brakes are working properly
- there is no unusual play in the stem and frame
- the tyres are inflated to the right pressure
- the gears are changing correctly
- the display isn't showing any errors
- the battery has plenty of charge

WHAT'S THE RIGHT PRESSURE FOR YOUR TYRES

To reduce the risk of getting a puncture and to make your pedalling as efficient as possible, we recommend inflating your tyres to between 3.5 and 4.5 bar (maximum pressure).

NB: check your tyre pressure every three weeks.

tyre pressure
How do you adjust the height of the seat post?

To keep you as comfy as possible in the saddle, we recommend adjusting it so that it is at hip height when you are standing next to it.

E FOLD 500: user guide, repairs

What are the minimum and maximum insertion limits for the seat post?

The saddle can be adjusted to fit cyclists from 1.45 m to 1.85 m tall. There are markings on the seat post to help you. There are markings showing your the minimum and maximum height to stop you raising the saddle too high.

FOLD LIGHT 1"
How do you adjust the length of the stand?

It can be handy to be able to adjust the length of the stand:
- when the ground is not straight, on a slight slope
- when your bike is more heavily loaded than normal, for example with luggage.

Electric folding bike E FOLD 100: user guide, repairs

How do you fold and unfold the pedals?

Each pedal can be folded by simply pulling it forwards and pushing it down.

FOLD LIGHT 1"

Troubleshooting

Something not quite right with your bike? Don't panic!
Whether it's the hinges, gears or even a punctured tyre, our FAQ is sure to have the answer to your questions!

The hinge and the drive train are grating

Accumulating dust and rain can cause squeaking over time. That's why it's important to maintain your drive train regularly.

We recommend the use of All in one lubricant (ref: 8650988)
Use this product to lubricate every rotating part that is accessible in the hinges.
Open and close the hinge three or four times to distribute the product.
Wipe away any excess product with a dry cloth.

E FOLD 500: user guide, repairs

There's some play in the frame's hinge

The lever may be a little loose, in which case we recommend tightening it. If that doesn't get rid of the play, please visit your local Decathlon workshop.

There's some play in the stem's hinge

Make sure the butterfly nut is tight enough. If this adjustment does not remove the play in the hinge, make an appointment at your nearest Decathlon workshop.

The hinge on the frame or stem is not locking properly

This is a safety element.
This issue should be resolved by a professional. Please get in touch with your local Decathlon workshop.

The bike won't fold

It may be difficult to fold your frame.
We recommend lubricating using our All in one product (ref: 8650988) to lubricate the hinge. Once you have done this, fold and unfold the bike several times.

Electric folding bike E FOLD 100: user guide, repairs

The bike's folded holding system is broken or deformed

You can replace this part by ordering it on our website.
The handling can be done by yourself or via a technician in the workshop of your store.

The bike's seat post is dropping by itself

Here's what to do to resolve this problem:
                                                                                                      1/ Clean the seat post with a damp cloth to remove any dust and other residue that has built up.
2/ Grease the inside of the clamp, making sure not to get any lubricant on the seat post itself.
3/ Put the clamp and saddle back on. Tighten the clamp to 4 Nm.

FOLD LIGHT 1"

The tyre is punctured or you have to change the rear wheel

If you've got a puncture, you can either apply a patch to the inner tube or replace it.
Important! Remember to unplug the motor cable before removing your bike's rear wheel.

The wheel needs changing

This should be done by a professional.
The wheel needs to be adjusted to a very precise torque using a special spanner.
Please get in touch with your local Decathlon workshop.

There is play in the headset

Use this video as a guide or visit your local Decathlon workshop and our technicians will be happy to help.

The brakes aren't working

There could be several reasons why your brakes aren't working:

- your brake pads are starting to wear out. Remember to adjust your brakes regularly so that they keep working efficiently.
- your brake pads are completely worn and need to be changed (you can find the pads in the spare parts shop)

YOUR BIKE IS NEW AND YOUR BATTERY WON'T TURN ON

1 - Check that the battery is correctly inserted and locked in place.
2 - Check that the battery is active and charged (the LEDs should light up when you press the battery button).
3 - Check that all of the cables are properly plugged in.

LOST KEY

You can make a copy of your key at any locksmith.

If you've lost both keys to your bike, please visit a Decathlon workshop to have the lock on the bike changed and your keys replaced.

YOUR BATTERY WON'T CHARGE

1. Check that there isn't any dirt in the way of the connection. Your battery and charger connectors should be clean and there should be no dirt inhibiting contact between the charger and battery

2. Check the battery > charger > mains socket connection. Check that the charger you are using is the original one provided by Decathlon. Plug the charger into the battery and a mains plug.

Steady red LED: battery is charging

Steady green LED: battery has finished charging

Flashing LED: there's a problem with the battery or the charger


It takes about 6 hours to fully charge the battery from empty.


3. One of the LED indicator lights on the battery may be defective.
We recommend taking your bike to a Decathlon workshop to have it repaired.


If the problem persists, please contact us through the contact form, or visit a Decathlon workshop.

THE BATTERY LIFE IS LOW OR HAS GONE DOWN

1. Make sure you follow the recommendations for using and storing your battery.

Your electric bike's range depends on a number of factors:

> THE BIKE’S LOAD: The range will be reduced if the bike is overloaded

> THE TYPE OF ROUTE: The range will be reduced on hills

> TYRE PRESSURE: The battery life will be better with tyres inflated to between 3.5 and 4.5 bars.

> THE OUTDOOR TEMPERATURE: The range is reduced in colder weather (by up to 50%).

> THE POWER ASSIST MODE: We recommend reducing the assistance mode when the battery is running low.

> YOUR PEDALLING CADENCE: You have to pedal in order to move.
An e-bike is still a bike, so you'll need to pick the right gear to suit your ride (e.g. gear 1 on steep slopes, gear 7 on flat ground).

> FOLLOWING THE INSTRUCTIONS FOR CHARGING AND STORING YOUR BATTERY:
Follow best practices to ensure your electric bike achieves its full range.

2. An old battery can have reduced performance.
The distance you can travel will therefore be reduced. Visit your Decathlon workshop to give your battery a check-up.

The electrical assistance isn't coming on / is jerky / is cutting out

The electric assistance starts after several pedal strokes, and only if the assist mode has been activated.

If the electric assistance still doesn’t start, follow these instructions:

1. Check that the battery is fully charged:

> Press the battery button.

> Check that at least one LED is lighting up.

> If one of the LEDs is flashing, recharge the battery by connecting it to its charger and a socket.


2. Check that the battery is clean, properly attached and locked in place:

> Check that the battery connectors and holder are clean and in good condition.

> The battery should be fully pushed into its holder.

When you push it in, it will click to indicate when it is correctly in place.

Lock the battery and remove the key.

3. Check all of the bike's connectors: brakes, motor, console, pedalling sensor, controller (controller = central processing unit of the electrical kit. It is located just behind the battery, on the pannier rack).

Most of the connectors can be accessed by opening or sliding off the neoprene covers that protect the electrical cables. The motor's connector is the only one that is not covered.

HOW TO CHECK THE BIKE'S CONNECTORS:

There are two types of connector on your bike: "screw-in" connectors and "push-in" connectors.

"Screw-in" connectors:

For "screw-in" connectors (which can be recognised from the two metal rings), you will need to unscrew both rings in order to disconnect the cables. Be careful not to lose the small plastic washer between the two rings when you unscrew them.

Once undone, check that each connector is clean, then reconnect it.

To do this, position the male and female connectors opposite each other. Make sure you line up the indicator arrows before pushing them in.

Screw the two metal rings as far as they will go to secure the connector.

"Push-in"connectors

The male connector is simply inserted into the female connector. Check that both connectors are fully inserted, and push them back in if necessary.

4. Test the electrical assistance:

> Turn on the screen by pressing the ON/OFF button.

> Get on your bike and pedal (you'll need to turn the pedals several times to trigger the electrical assistance).

If the problem persists, submit a support request or visit a Decathlon workshop.

The display and assistance cut out when hitting a bump or going off a pavement

Check that the cables are properly connected.
You should also check that your battery is securely locked onto the pannier rack.

THERE'S A FLASHING LED ON YOUR BATTERY OR NO LED

> The first LED is flashing: The battery is almost empty and needs to be charged. Plug it into its charger and connect it to a mains socket to charge it.

> The second LED is flashing: The battery is in "undervoltage" protection mode due to improper handling or a long period without recharging. Plug it into its charger as soon as possible and connect it to a mains socket to charge it and take it out of its protection mode.

> If there is another flashing LED or several flashing LEDs, the battery is faulty. Take your battery to a Decathlon workshop for full testing.

Electric folding bike E FOLD 100: user guide, repairs

OUR WORKSHOP SERVICES

Does your bike need repairing? Make an appointment at one of our Decathlon workshops or with one of our partners.

E-bike FAQs

Got a question about your e-bike?
Here are the questions most frequently asked by our users.

How to turn your front and rear lights on and off?

See video:

E FOLD 500: user guide, repairs

Where can you buy a replacement battery?

You can order a new battery from our website. Just head to the spare parts department. Ref: 8801778.
You can also get one from the store at your Decathlon workshop.

WHAT SHOULD YOU DO WITH THE BATTERY WHEN IT WEARS OUT?

When your battery wears out, take it to your local Decathlon store. We'll send it to a specialist facility to be recycled.

HOW SHOULD YOU STORE YOUR BATTERY?

You should store your battery somewhere cool (between 10°C and 25°C) and dry, out of direct sunlight.

To avoid deep discharge, which may cause it to malfunction, do not store the battery when empty (1 flashing LED).

You should charge the battery (even if it's not being used) at least once every three months to prevent deep discharge and loss of the battery's capacity.

If you can't charge your battery regularly, put it into standby mode (even though it automatically goes into standby mode after 2 hours).

WHAT IS THE LIFETIME OF YOUR BATTERY?

The warranty on your battery is for 2 years or 500 charge cycles (1 cycle = 1 full charge + 1 full discharge).
After these 500 charging cycles, the battery is no longer guaranteed but still works (not to its full capacity).

SHOULD YOU WAIT UNTIL YOUR BATTERY IS COMPLETELY FLAT BEFORE CHARGING IT?

No. Lithium-ion batteries have no memory effect and can therefore be charged at any time.

We recommend charging your battery regularly to keep it working well.

HOW LONG CAN YOU STORE YOUR BATTERY BEFORE YOU NEED TO RECHARGE IT?

The battery is equipped with a standby mode that allows it to be stored without having to be charged regularly.

Once set to standby mode (hold down the battery's on/off button), the battery can be safely stored for up to 1 year without being charged and without this affecting the capacity.

A battery stored without being set to standby mode needs to be charged at least every 3 months to prevent the battery capacity deteriorating.

Can you leave the charger connected to the battery even after it has finished charging?

We strongly recommend against leaving your battery plugged in when unattended, for example overnight.

For your information: once the battery is fully charged, the charger will automatically shut itself off (the LED indicator on the charger stays on).

DOES THE BATTERY CHARGE WHILE CYCLING?

No, it doesn't have a dynamo.
Some systems let you charge the battery as you ride or brake. But this doesn't generate much power. You'd have to ride several dozen kilometres to generate 1 km of additional power.

CAN YOU RIDE WHEN YOUR BATTERY IS FLAT?

The bike provides electric assistance, but you can still ride it without the assistance.

Of course, the extra weight of the motor system will make cycling a little harder.

CAN YOU RIDE WHEN IT'S RAINING? ARE THE COMPONENTS WATERTIGHT?

The battery is designed to be used when it's raining, but it shouldn't be submerged in water or washed with a pressure washer.

The same is true for the display and the other components and electrical cables.

Nevertheless, we recommend sheltering your bike as much as possible when you're not riding it.

NEED A SPARE PART?

You can find spare parts for your folding bike in our workshops and on our website.

SERVICING YOUR BIKE

How to make your bike last longer

To keep your bike working reliably, it's important to service it regularly!
Regular maintenance is important if you want to keep your bike working efficiently for as long as possible, so we've put together some tips to help you service your bike.

1. Before each ride, make sure your tyres are inflated to between 3.5 and 4.5 bar.
2. Clean and lubricate your bike's drive train.
3. Regularly check the brake pads and tyres for wear.
4. Clean it regularly in accordance with the instructions

SERVICING YOUR DRIVE TRAIN

We strongly recommend lubricating your drive train regularly so that it runs smoothly.

The easiest way to do this is by using a workstand.
Put your chain onto the small cog and apply the lube along the entire length of the chain, between the links and on the inside.
Next, use your hand to turn the pedals as you shift through the gears. With each gear shift, the chain will move from one cog to another and distribute the lube over the entire drive train system, including the derailleur.
Lastly, use a microfibre cloth to remove any excess lubricant from the chain. Your bike is now ready to go again!

Another solution is to put lubricant on a toothbrush and then hold it under the chain as you turn the pedals.
You can then use the toothbrush on the cassette and derailleurs if you feel they need a bit more lube.
This technique stops you using too much lubricant, which would be wasteful and lead to dirt building up on the drive train more quickly.

Hinges should be lubricated every 3 months

Your bike's hinges are very important. They're going to be exposed to rain, dust and the worst of the weather. That's why they should be lubricated regularly.
We recommend doing this:
- every three months
- or when the hinges are grating

You can use our All in one product (ref: 8650988).

Adjusting your brakes

Over time, the brake pads will wear out. For this reason, we recommend adjusting the brakes every three months.

Cleaning the seat post

Clean your seat post regularly with a damp cloth so that it keeps sliding smoothly.

Check the tyre pressure regularly (every three weeks)

It's important to check your tyre pressure regularly.

When the tyres are inflated to the right pressure:
- the bike is more efficient
- there's less risk of you getting a puncture

We recommend inflating your tyres to 4.5 bar max.

E FOLD 500: user guide, repairs

GET KITTED OUT

Explore all of our accessories for making your commutes easier!
Accessorise your bike and get from A to B hassle-free. Enjoy!

How to mount the 1 Second Clip front bag

See video:

Electric folding bike E FOLD 100: user guide, repairs

Can this bike take a child seat?

No, this bike's geometry means that you can't install a child seat. And the pannier rack isn't designed to take the extra weight.

Can this bike take a child trailer?

No, our bikes are not compatible with child trailers.

Can you change the saddle?

Yes, you can change your saddle if it doesn't suit you in terms of ergonomics or comfort.
Compatible saddles are those designed for a 60° back position.

FOLD LIGHT 1"
