INCLINE RUN

REF: 8580105

INCLINE RUN

2019

In stores: December 2019

Designed for walking or running at a steep angle. This treadmill helps you boost your performance, develop your power and accelerate calorie burn.

BENEFITS:

VERSATILITY: Intensify your workouts with a max speed of 18km/h and a max incline of 20%

USER COMFORT: A large running surface designed for long strides: 51 x 135 cm

COACHING: 40 pre-set programmes + compatible with the Domyos Econnected app

Assembling and setting up

Thank you for purchasing a Domyos product. To help you get your equipment up and running, click on the video to see the different set-up steps.

INCLINE RUN assembly video

Problems

Is your equipment properly set up but you're still having an issue when using it? See all our FAQs here.

How do i pair my remote control?
Your console isn't showing the right speed

Before you start, make sure your treadmill is plugged in to the mains. 1. Press the "STOP" button. 2. Hold down the "STOP" button and insert the "SAFETY KEY". 3. The units being used are displayed in the bottom right corner:     UNIT MI   or  UNIT KM. 4. Press "+" to change the unit. 5. Press "STOP" to confirm the changes. 6. You can now use your treadmill.

INCLINE RUN
Operation: bluetooth, usb, jack.

1- The Bluetooth symbol lights up and indicates that a tablet or smartphone is connected to the console. This only works with the “Domyos Econnected” app for IOS and Android.     Econnected FAQs: https://support.decathlon.fr/support/application-e-connected-tp_1079 2- The USB port is only there to keep your tablet or smartphone charged when using your treadmill. 3- The jack socket is only there for connecting your MP3 player, tablet or smartphone to your console.

Console: Bluetooth, USB, jack
How can you see the total distance and time run on the treadmill?

To see how far and how long you've run since starting to use your treadmill, remove the safety key and press "STOP" + "-" simultaneously then insert the safety key. Press the START button 7 times to show the total distance run on the speed display, or press the START button 9 times to show the total amount of time run on the speed display.

INTENSE RUN KM
Your treadmill doesn't switch on

1. Check that the power cord is plugged into a working mains socket (to check if the wall socket is working, plugin a lamp or other electrical device).2. Check that the other end of the power cord is connected to your treadmill.3. Check that the main switch near the power cord is set to I.4. Check that the safety key is pushed fully home in the console.

INCLINE RUN
Your treadmill is making a noise

1. Shoes: => The noise you can hear could be the sound of your shoes on the running belt. To check that the noise isn't coming from your shoes, please see the video below   2. The screws are loose:  => Tighten all of the screws.   3. The running belt is wonky: => Select the "CENTRING THE RUNNING BELT" tab in the MAINTENANCE section.   4. The running belt is not lubricated: => Select the "RUNNING DECK LUBRICATION" tab in the MAINTENANCE section.

The treadmill slows down when you step onto it

The running belt is slack => Select the "RUNNING BELT TENSION" tab in the MAINTENANCE section.

The treadmill switches off during use

1. If your treadmill is plugged in to an extension cable, unplug it and plug it directly into a wall socket. 2. The problem could be caused by the power cord. In this case, please see the FAQ on ""YOUR TREADMILL IS NOT SWITCHING ON""

I'm having trouble with my heart rate monitor belt

1. To pick up your heart rate accurately, the distance between your heart rate monitor and the console should be no more than 80 cm. 2. To pick up your heart rate accurately, adjust the position of the belt so that the sensors are in contact with your skin. Moisten the sensors well before use. As the diagram shows, the sensors are the black rubber surfaces on either side of the central part. 3. There are also other things that may affect how well your heart rate is picked up, such as clothing that knocks against the belt or that is very static, a very hairy chest, and traces of dirt on the belt. 4. The display is blinking or not functioning normally The battery is probably low, so you will need to charge it.

HRM BELT
I can't get my treadmill to work in manual mode

Check that the icon on your treadmill's console is off.

INCLINE RUN
Parts diagram
Incline Run exploded diagram
INCLINE RUN

Not able to fix your problem or find the right answer?

PLEASE CONTACT ONE OF OUR TECHNICIANS.

Servicing your product

It takes care of you, so you should do the same for it. Regular maintenance is necessary to preserve the performance of your equipment and extend its service life.

Centring the running belt

You will need the Allen key (BTR) that came with your treadmill:  1. Start your treadmill at a low speed (4 km/h).        2. Insert the key into the screw on the side where the running belt is off-centre.        3. Turn it a quarter turn clockwise (wait 30 seconds between each quarter turn) until the belt is back in the correct position.



Running belt tension

The running belt is a wearing part that becomes loose over time. Re-tighten it as soon it begins to go slack (sliding sensation, jerky motion).



1&2. Turn the two adjustment screws a half turn clockwise (repeat if necessary, but make sure you don't over-tighten the belt).



3. The belt is properly tightened if you can lift the edges 2 to 3 cm on each side.

Running deck lubrication

It's important to do this regularly (every 200 hours of use) to keep your treadmill working as long as possible.  1 & 2. Simply spray twice underneath the running belt on the right and on the left.  3. Then set your treadmill off at 5 km/h for 5 minutes, without standing on it.

Running deck lubrication

Maintenance instructions

Regular maintenance is necessary to preserve the performance of your appliance and extend its service life. To get rid of any annoying noises coming from your treadmill, remember to:

                       Tighten the screws and bolts once a month.

                       Lubricate the running belt after 200 hours of use.

                       Place a standard floor mat (Domyos Training Mat) under your treadmill.



CLEANING AFTER EACH USE:

                      Turn off and unplug your treadmill.

                      Apply a small amount of gentle universal cleaner to a pure cotton cloth. Do not spray the cleaner directly onto the treadmill and do not use ammonia or acid cleaners.

                      Wipe the console and screens.

                      Remove any dust and stains on the ramps, uprights, footrests, frame and motor hood. Remember to also wipe the platform alongside the running belt. Do not clean under the running belt.

Preventative maintenance

1. Check the motor and the drive belt every 600 hours of use or every 3600 km*2. Replace the running belt every 500 hours of use or every 3000 km*3. Replace the running deck every 700 hours of use or every 4200 km*4. Replace the rollers every 600 hours of use or after 3600 km*



*To know the accumulated hours or kilometres, refer to the FAQ "HOW TO SEE THE TOTAL DISTANCE AND TIME RUN ON YOUR TREADMILL" in the SETTING UP AND USING YOUR PRODUCT section

Order spare parts for this product

NEED SPARE PARTS FOR YOUR INTENSE RUN TREADMILL?

Instructions

  • INCLINE RUN

    Need the product's user guide? Click to download.

INCLINE RUN

Composition / advice

Composition :

Frame // Chassis (for the rollers): 100% steel

Hood: 75% polystyrene (PS), 25% polyvinyl chloride

Packaging: 85% cellulose, 10% expanded polystyrene, 5% polyethylene terephthalate (PET)

Deck: 40% copper, 35% steel, 10% brass, 10% epoxy, 5% aluminium

USE RESTRICTION:

Maximum user weight: 130 kg

INCLINE RUN

Our commitments

Domyos guarantees this product under normal conditions of use for five years for the structure and two years for other parts and labour from the date of purchase shown on the receipt.
