TC 790

The treadmill is not connected correctly


           => Check the connection of the mains socket, then make sure that the treadmill's main switch is set to \"1\"
           => Then check that the safety key is in position
           => Check and press the circuit-breaker if it has tripped

The belt is dry:


           =>Lubricating the running belt
           =>If the belt is dry, spray silicone as shown on the pictures
           2 pulverizations on each side is enough

           =>Let the treadmill run for 5 minutes to allow the silicone to spread on the whole belt

           => It is important to perform this operation regularly (every 10 hours of use) in order to get the maximum lifespan from your treadmill


The treadmill belt is off-centre


First step :
Use the Allen key provided with your product

Second step :
1 - Run your treadmill at 4 km/h

2a - If the belt if off-centre to the left, turn the left-hand adjusting bolt a quarter of a turn clockwise.


2b - If the belt is off-centre to the right, turn the right-hand adjusting bolt a quarter of a turn clockwise.

3 - Let the treadmill run a few seconds for the belt to reposition itself

4 - Repeat the procedure if necessary

The screws are loose
           => Tighten all the screws in the uprights

The running belt is not centred
           => Refer to chapter \"Centering the running belt\"



The running belt is not properly lubricated
           => Refer to chapter \"Lubricating the running belt\"



Check that the running belt is correctly tightened

           => Refer to chapter \"Adjusting the tension of the running belt\"



Stage 1:
Use the Allen (hex) key provided with your treadmill

Stage 2:
1) Press the \"GO\" button

2) Increase the speed up to 5 km/h

3) Turn the two adjustment screws one quarter turn clockwise

4) If needed, repeat stage 3

Click \"NO\"

Running belt tension is too high

           => Check the running belt tension so that the movement of the belt between the board and belt is about 3 centimetres at the middle of the board

           => If this is not the case, turn the two hex screws at the rear of the treadmill on each side of the roller and then loosen the running belt
