Triban GRVLW120

REF: 8587697

TRIBAN GRVL 520 SUBCOMPACT

2020

Need help assembling, maintaining or repairing your bike?

Find all our tips, tutorials and videos as well as user guides and spare parts for your GRVL 520 right here!

Assembly video

First use

It's worth getting into good habits right from the first time you use your bike. We've put together all sorts of helpful tips on gravel riding and looking after your bike.

Triban GRVLW 120 Women's Gravel Bike (2020) (duplicate)
Things to check before every ride tyre-brake-lubricant-bolts-derailleur
First use
Ready for your first rides? Decathlon Outdoor
Brakes: adjusting the calliper

Once you've assembled your gravel bike, your brakes might need adjusting. This video explains how to do it.

Tyre: the right pressure

For gravel riding, the tyre pressure has to be just right because the bike will be used on a range of surfaces. You'll need to adapt the pressure based on the total weight, the type of terrain and the tyre itself. On your particular bike, we recommend following the advice in the link below.

These numbers are for reference only. You're more than welcome to experiment and adjust the pressure based on how it feels as you ride.
You'll find the minimum and maximum pressures on the tyre's sidewall.

Tyre: switching to tubeless

Before you get started, make sure you have compatible tubeless-ready tyres.

Our tutorial video shows you how to fit your tubeless tyres.

Seat post: tightening the seat post

To set your saddle correctly it needs to be securely in place. A loose seat post can slip when you're out and about on your bike. Conversely, if it's too tight, you run the risk of crushing the seat post and damaging your bike.

The best way to tighten a seat post is to use a torque wrench. We recommend you tighten it to between 6 and 7 Nm.

Take care not to exceed the maximum height indicated on the seat post.

Storage

If you're not going to be using your bike for a long time, you should:

> Store your bike somewhere cool and sheltered.

> Clean it, before putting it away, to remove mud or sand that could corrode it.

- Lubricate the chain. Spray some All-In-One over the entire bike to protect it from rust

- Put the chain onto the smallest cog

- If your tyres are tubeless, check the level of sealant in them before you use your bike again. If the wheels don't turn for a long time, the liquid can solidify and stop working

Safety

We recommend wearing a helmet and gloves while riding. Anyone can take a tumble, and you'll be grateful for your helmet and gloves when it inevitably happens!

First use
Triban GRVLW 120 Women's Gravel Bike (2020) (duplicate)

Maintenance

Servicing your GRVL 520 will keep all of its parts working for as long as possible and ensure you have the most fun when riding. Aside from the aesthetic aspect of having a clean bike, failing to service it can lead to problems, and problems lead to accidents: jammed cables, rust, leaks, premature wear, etc.

Extending the lifespan of your bike's parts means a lower environmental impact.

As soon as you start using the bike, some components will move slightly.
This is why we offer a free check for your bike 6 months after purchase.

With a gravel bike, you're going to be riding on both roads and mud. At some point, you'll have to change various components to keep your bike in good nick.

Brakes: changing your brake pads

To find out if your pads are worn, check the thickness of the brake lining on the pad. You'll need to change the pads if the lining is less than 0.5 mm thick.This video shows you how to change your brake pads.

After replacing your brake pads we recommend bedding them in so that they don't "seize up" (which would cause weaker braking power).

Tyre: changing a tube-type tyre

Your tyre might be quite stiff if it's old, so you may need to use some force to get it off.

You'll find the right tyres in the link below.

Tyre: changing tubeless gravel tyres

Your tyre might be quite stiff if it's old, so you may need to use some force to get it off. We recommend that you don't reuse the old sealant.

You'll find the right tyres in the link below.

Cassette: changing your cassette

To change your cassette, you'll need the right lock ring and a chain whip. You'll find both of these tools in the link below.

Chain: changing your chain

To do this, you will need: a chain tool, a new chain, and a quick-link.

Place the chain on the last cog and on the smallest chainring.

Remove the quick-link using the pliers or chain tool, then take the old chain off the drivetrain.
IMPORTANT: certain chains only fit in 1 direction, be sure to check the user guide.

Place the new chain on the last cog and on the smallest chainring. This will make it easier to determine its optimal length.

The chain should pass close to the top pulley of the upper jockey wheel on the derailleur.

Once you've determined the correct length, use the chain tool to cut the chain.

Lastly, install the quick-link onto the chain, turn the pedal so as to position the quick-link on the upper part of the chain, and use your hand to apply pressure and ensure it is firmly locked in place.

Need equipment to repair or maintain your bike? Here are the essentials.

Have a problem?

Have you suddenly encountered a mechanical problem, or are you struggling to service your bike somehow? We've created a range of tutorials covering the most common maintenance jobs that you're likely to have to do.

Pedals: mounting clipless pedals

Are your pedals broken? Do you want to change your pedals for clipless ones? Here's our advice.

NB: please note that the screw thread on the left pedal is inverted and that the pedal thus screws on in an anti-clockwise direction. The right pedal has a normal thread.

Make sure to use the correct tool to remove your pedals as you will need to use some force to unscrew them.

Brakes: the disc is making a noise

If your disc makes noise:

- Check that your wheel is properly centred. To do this, loosen the wheel and tighten it up again.

- Check that your calliper is correctly adjusted and that the brake cables are set at the right tension.

- Check that the disc is straight.

- Clean the entire brake system with water. If necessary, clean the discs with some water and soap.

The brakes might make a noise if they haven't been bedded in properly. In this case, follow the bedding-in procedure.
If you've been braking very hard over a long period (for example, when going down a steep hill), your brake pads might have glazed over and/or your disc could have overheated. In this case, replace your brake pads and discs.

Brakes: if they aren't braking very well

There are several things you can do if your brakes aren't working as well as they used to:

- Clean your bike, discs and brakes with soapy water

- Check your brake pads for wear.

- Check that the cable is properly tensioned.

- Check that the calliper is properly centred.

Housing: changing brake cables / housing

TRP brakes require specific actions. To handle them properly, here is a video from TRP that explains what to do.

If you have the slightest doubt, come see us at our in-store workshop.

To replace your brake cables and housings, remember to get an anti-compression brake cable housing, which you can find at the link below.

Housing: changing gear cables / housing

Changing your gear cable means adjusting your derailleur. This requires specialist skills and knowledge. We don't yet have a video or tutorial that easily explains how to do this, so we recommend contacting one of our workshops, where our experienced mechanics will be happy to help.

Your gears are not shifting properly

There could be several reasons why your gears (cogs) are not shifting correctly.

1. Incorrectly positioned cable housing caps can hinder the pulling action on the derailleur cable and cause the shifting of the gears to be off. If a housing end is out of position, push it back into place.

2. The cable and housing might be jammed. If you can't shift into the smallest gears (onto the smallest cogs), and if the derailleur doesn't move even when the gear shifter is operated, then the cable and the housing have jammed up. In this case, the cable and housing need to be replaced.

3. Check that the derailleur hanger isn't bent. If it is, see the "BROKEN DERAILLEUR HANGER" section

4 . Bring your gravel bike to a Decathlon workshop, where we can adjust the derailleur

NB: If you regularly ride your gravel bike in wet or muddy conditions, or if you regularly wash it with a lot of water, then your cables and housing will need to be replaced more frequently. Washing your bike using a high pressure hose is highly discouraged as it can push dirt and dust into the cable housing.

Changing your derailleur hanger

You'll find the derailleur hanger for your bike in the link below

Upgrading your gravel bike

We offer a full range of accessories that are compatible with your GRVL 520.

Triban GRVLW 120 Women's Gravel Bike (2020) (duplicate)
Triban GRVLW 120 Women's Gravel Bike (2020) (duplicate)

Our workshop services

Get your bike repaired at one of our stores!
Our qualified mechanics will be happy to help.

User guides

Triban GRVLW 120 Women's Gravel Bike (2020) (duplicate)

Our
commitment

Riverside is committed to reducing carbon emissions related to its bicycle production processes to the greatest extent possible.
Each part is designed to have the lowest carbon footprint possible.

We provide a lifetime warranty on the frame, stem and handlebar. All other parts have a 2-year warranty.

When you start using your bike, some of the components may move a little. That's why we offer a free check-up in the first three months following the date of purchase.

Triban RC 520 Subcompact - 2020

Haven't been able to fix your problem or find what you need?

Please contact one of our technicians who will be happy to help
