VAN RYSEL WOMEN'S RC 120

2021

Welcome to the support sheet for your WOMEN'S RC 120.

This page contains all our very best advice for using, maintaining and repairing your RC: user guide, servicing, repairs and spare parts.

UNBOXING

FIRST USE

To help you get to grips with your new ride, here are some tips on using your RC for the first time.

  • Van Rysel EDR CF disc Rival AXS women's power meter

    TYRE PRESSURE

    For your first outing, remember to choose your tyre pressure, depending on the weather conditions and your weight.

  • Van Rysel EDR CF disc Rival AXS women's power meter

    BEDDING IN THE BRAKE PADS

    Running in the brake pads is vital when using a bike for the first time.

    To run them in properly, we recommend you brake 20 to 30 times at over 25 km/h, without locking the wheel.Also make sure you don't stop between braking to avoid "freezing" and thus sticking the pads to your discs.

  • Van Rysel EDR CF disc Rival AXS women's power meter

    TORQUE SETTINGS

    Please respect the torque settings, especially the settings for the stem/handlebars (please see the user guide), which can cause a fall if they are not tightened properly.

    To set your position properly on the bike, carry a set of Allen keys with you on your rides.

MAINTENANCE

Maintaining your bike is essential if you want to expand its lifecycle. That starts with regularly cleaning your bike, the frame and drive train.

  • Van Rysel EDR CF disc Rival AXS women's power meter

    Step 1

    Apply a degreaser to your drive train. Place a cloth on top of the brake discs to prevent them from being covered with degreaser.

  • MAINTENANCE

    Step 2

    Clean your drive train with the aid of a brush. Apply a suitable cleaning product to your frame.

  • MAINTENANCE

    Step 3

    Drying your bike and lubricating your drive train.

Essential tools for your workshop.

To maintain your bike correctly, you need to have the right tools.

What to check before you ride

Read the article below to find out what checks you need to make on your bike before going out for a ride:

What checks do you need to make before going out on the bike?
Selecting the right tyre for your RC

The tyre is the only element in contact with the ground. To minimise the risk of it losing grip, it's essential to choose the right type of tyre, and adapt the pressure accordingly.

Check out our advice here:

When to change your tyres

Riding with worn tyres comes with risks:

Loss of grip.

Greater exposure to punctures.

In this article, we'll tell you how to spot a worn tyre:

Adjusting and tightening the seatpost

To set your saddle correctly it needs to be securely in place. A loose seat post can slip when you're out and about on your bike.
If you tighten it up too much, however, you run the risk of crushing the seatpost and damaging your bike.


The best way to tighten a seat post is to use a torque wrench. We recommend you tighten it to between 6 and 7Nm.


Take care not to exceed the maximum height indicated on the seat post.

Replacing your bike chain

The chain is an essential part of your bike's drive train. The following are tell-tale signs that you need to change it:
- The chain starts jumping.
- The chain has been on for more than 5,000 kilometres.
- Gear changes are not smooth.

To find out more read our article:

Changing your brake pads

The following are all signs that you might need to change your brake pads:

- You don't have the same responsiveness as when you bought your RC and there's a lack of bite.
- Your bike makes a strange noise when you brake sharply.
- The thickness of the pad is below 0.5 mm.

Changing your brake discs

Although disc brakes are designed to wear out the brake pads and not the disc, the disc will eventually wear out where there is heavy use.

It can be dangerous to ride with an overly worn disc; it can give out if you brake suddenly or intensely.

The maximum wear value of the thickness of the disc is around 10% of its original value. We strongly recommend that you change it when the wear exceeds that figure.

Greasing the bearings on your bike

To ensure your frame lasts longer, grease the bearings and abrasive parts of your RC bike regularly. You should be keeping a close eye on the following:

- Bottom bracket.
- Steerer tube.
- Wheel bearings.
- Seatpost.

Your drive train makes noise

If your drive train is too noisy and/or your gears don't shift properly, you certainly need to adjust your derailleurs.

Find out how in the following video:

Replace the cables

There is no special number of kilometres to know when to replace your cables.

It depends on your practice of cycle touring/sport cycling/competition;

But also depends on how delicately you change gears - that is, if you change gears very regularly during your rides or not.

The first signs of wear are:

Is it challenging to change gears?
Even after adjusting them!
That means it might be time to replace your cables before they give out in the middle of a ride.

Also, if you notice that a housing or a cable is fraying, don't wait to replace it

Repairs

CHANGING YOUR PEDALS

Are your pedals broken? Do you want to change your pedals for clipless ones? Here's our advice.

NB: please note that the screw thread on the left pedal is inverted and that the pedal thus screws on in an anti-clockwise direction. The right pedal has a standard thread.

Make sure to use the correct tool to remove your pedals as you will need to use some force to unscrew them.

Changing your inner tube

If you pick up a puncture, our tutorial will tell you how to change your inner tube.

Changing your handlebar tape

The tape on your handlebar will wear over time and you'll need to change it occasionally.

Your bike isn't braking as well as it used to

There are several things you can do if your brakes aren't working as well as they used to:

- Clean your rims with a degreaser

- Check the brake pads for wear.

- Check the tension of the cable.

YOUR DISC BRAKES ARE MAKING A NOISE

If your disc makes noise:

- Check that your wheel is properly centred. To do this, loosen the wheel and tighten it up again.

- Check that the brake calliper is in the right position.

- Check the brake pads for wear.

- Check the tension of your brake cables.

YOUR GEARS ARE SKIPPING

If the gears are skipping, you should check the following:

- The wear on your drive train.

- The tension of the cables.

You then need to adjust the derailleur.

THE DERAILLEUR HANGER IS BROKEN OR BENT

If your derailleur hanger is broken or bent, you need to change it.

Replacing your cassette

Is your drive train worn? Do you need to change the number of cogs on your cassette?

Watch our tutorial to find out how to change your cassette.

Replacing the brake cables

Here's a video explaining how to replace your brake cables:

Replacing my derailleur cables and housings

Need to change your derailleur cables and/or housings?

Check out this tutorial:

YOUR DISC BRAKES ARE MAKING A NOISE

If your disc makes noise:

- Check that your wheel is properly centred. To do this, loosen the wheel and tighten it up again.

- Check that the brake calliper is in the right position.

- Check the brake pads for wear.

- Check the tension of your brake cables.

Replacing my chainrings

Are your chainrings worn? Do you want to change the number of teeth?

It's easy to change your chainrings.

All you need to do is use an Allen key to unscrew the screws holding the chainrings in place.
Then install the new chainrings.

Replacing your front derailleur

Watch the following video to learn how to change your front derailleur:

SPARE PARTS

Van Rysel EDR CF DB Shimano Ultegra (2021)

Assistance

Need a hand? Ask our expert technician!

Instructions

FEATURES

Van Rysel RC frame

VAN RYSEL WOMEN'S RC 120: user guide, repairs
Van Rysel EDR CF disc Rival AXS women's power meter

OUR PLEDGE

VAN RYSEL offers a 5-year warranty on your RC frame.

All other parts have a 2-year warranty.
